UGRT Series Rice Transplanters Features:
1.The machine is light in weight and small in size, achieving harmony between man and machine, and light operation;
2.The engine has large horsepower, which can realize high-efficiency rice transplanting operations;
3.Use bevel gear transmission to ensure accurate and reliable power transmission;
4.Equipped with automatic balance of the machine body, which can achieve consistent seedling depth;
5.Using a stable rotating rice transplanting mechanism, higher reliability;
6.The oil bath type seedling delivery box is adopted to improve the reliability and durability of use;
7.Adopt large-diameter wheels to improve the adaptability and passability for poor field operations.
Model: UGRT-4, UGRT-6
UGRT Series Rice Transplanters Features:
1.The machine is light in weight and small in size, achieving harmony between man and machine, and light operation;
2.The engine has large horsepower, which can realize high-efficiency rice transplanting operations;
3.Use bevel gear transmission to ensure accurate and reliable power transmission;
4.Equipped with automatic balance of the machine body, which can achieve consistent seedling depth;
5.Using a stable rotating rice transplanting mechanism, higher reliability;
6.The oil bath type seedling delivery box is adopted to improve the reliability and durability of use;
7.Adopt large-diameter wheels to improve the adaptability and passability for poor field operations.
Rice transplanter technical specification:
|
Model |
UGRT-4 |
|
|
Structural type |
Two wheels three floating plates type |
|
|
Wheel diameter (mm) |
￠660 |
|
|
Work part structural type |
Crank rocker type |
|
|
Size (L×W(when working)×H) (mm) |
2140×1630×910 |
|
|
Total weight (kg) |
170 |
|
|
Engine |
Model |
YAMAHA MZ175B8EA0 four-stroke single-cylinder gasoline engine |
|
Output power(kW)/revolving speed(r/min) |
3.3/3600 |
|
|
Shifting gear |
Forward: 2 speeds Reverse: 1 speed |
|
|
Capability |
Working speed (km/h) |
1.00-2.77 |
|
Speed of travel on road (km/h) |
2.09-5.33 |
|
|
Planting width(mm) |
7-37 |
|
|
Planting density |
Number of rows |
4 |
|
Row spacing (mm) |
300 |
|
|
Transverse feeding seedling quantity(mm/time) |
10.8/26 14/20 15.6/18 |
|
|
Longitudinal taking seedling quantirty(mm) |
8-17 |
|
|
Transplating distance (seedling to seedling) (mm) |
120 140 160 180 210 |
|
|
Number of hills (each 3.3m2) |
90 80 70 60 50 |
|
|
Number of seedlings per hill |
2-8 |
|
|
Model |
UGRT-6 |
|
|
Type |
Two wheels three floating plates type |
|
|
Diameter of wheel (mm) |
660 |
|
|
Work-part structural type |
Crank rocker type |
|
|
Dimensions (L×W(when working)×H)(mm) |
2370*1930(2280)*930 |
|
|
Total weight (kg) |
195 |
|
|
Engine |
Model |
YAMAHA MZ175B8EA0 four-stroke gasoline engine |
|
Output power (kW)/rpm(r/min) |
3.3/3600 |
|
|
Shifting gear |
Forward: two speeds Reverse: one speed |
|
|
Capability |
Productivity (hm2/h) |
0.1-0.32 |
|
Working speed (km/h)（non-slip） |
1.22-2.77 |
|
|
Speed of travel on road （km/h） |
2.09 |
|
|
Planting width（mm） |
4-40 |
|
|
Planting density |
Number of rows |
6 |
|
Row spacing （mm） |
300 |
|
|
Horizontal feeding seedling quantity(mm/time) |
15.6/18, 14/20, 10.8/26(20/14) |
|
|
Vertical taking seedling quantity(mm) |
8-17 |
|
|
Transplating distance (seedling to seedling) (mm) |
120, 140, 160, 180, 210 |
|
|
Number of hills (each 3.3m2) |
90, 80, 70, 60, 50 |
|
|
Number of seedlings per hill |
3-5 (adjustable) |
|
|
Seedling condition |
Seedling type |
Seedling with soil |
|
Height of seedling (mm) |
100-250 |
|
|
Leaf age (years) |
2-4.5 |
|
Any change of technical parameters, there is no further notice.
